RH13 Box Type Dock Leveller with Hinged Lip
Description
The RH13 Box Type Dock Leveller with a 400 mm hinged lip integrates the pit and dock leveller into a single prefabricated unit for industrial loading bays. It supports loads of up to 6,000 kg (up to 15,000 kg in specific configurations), features a 6/8 mm chequer plate platform, and incorporates a hydraulic operating system. CE compliant, it is ideal for warehouses with high traffic volumes. It simplifies installation while maintaining maximum safety and functionality.
Main Features
- Prefabricated Box structure: pit and dock leveller integrated into a single unit.
- 400 mm hinged lip for secure truck connection.
- Quiet hydraulic system with dual cylinders.
- Dynamic load capacity of up to 6 tonnes (60 kN).
- 6/8 mm anti-slip chequer plate platform.
- Includes side toe guards, safety maintenance strut, and anti-drop valve.
- Compliant with European Standard EN 1398.
Benefits
- Reduces construction errors and improves installation times.
- Ideal for turnkey projects and industrial developers.
- Lower civil engineering costs.
- Factory-integrated safety features for enhanced protection.
Why choose this model?
The RH13 box-type model is the ideal solution when both the dock leveller and the pit are required as a single integrated system. Its prefabricated design combines the pit and dock leveller into one unit, reducing installation times and ensuring precise levelling directly from the factory. Perfect for new-build facilities, turnkey projects, and industrial developments where tight deadlines and trouble-free installation are essential.
